| 产 品 规 格 书 | |||||
| j9九游会·产品名称：WL-500D高速全自动丝印机 | |||||
| 一、标准配置(Standare Accessoriesw) | |||||
| 序号No. | 名称(Name) |
技术规格 (Specification) |
单位 Unit |
备 注 | |
| 1.1 | 送料机（Unwinder） | 1 | Set | ||
| 1.2 | 印刷主机(Mian Machine) | 1 | Set | ||
| 1.3 | 倒卷机（Rewinding Machine) | 1 | Set | ||
| 1.4 | 网框(Set Screen Frame) | 4 | Set | ||
| 1.5 | 烤箱(Drying Box) | 1 | Set | ||
| 1.6 | 刮墨刀(Scraper) | 3 | Set | ||
| 1.7 | 回墨刀(Ink-Rrturn Blade) | 3 | Set | ||
| 1.8 | 工具箱(Tool Box) | 1 | Set | ||
| 1.9 | 说明书(Operation Manual) | 1 | Set | ||
| 二、规格参数(Specifications) | |||||
| 2.1 | 网框面积(Screen frame size) | 700×1100 | mm | ||
| 2.2 | 最大印刷面积(Max.print area) | 500×700 | mm | ||
| 2.3 | 最大纸宽(Max.paper Width) | 500 | mm | ||
| 2.4 | 最大拉纸(Max.paper Forward) | 700 | mm | ||
| 2.5 | 印刷速度(Printing Speed) | 0-6000 | rph | ||
| 2.8 | 主机尺寸（L×W×H）(Machine Size) | 3500×1400×1800 | mm | ||
| 2.8 | 烤箱尺寸（L×W×H）(Drying Box Size) | 2800×1000×2500 | mm | ||
| 2.9 | 机械重量 | 净重(Net Weight) | 1600 | kgs | |
| 装箱(Gross Weight) | 2100 | kgs | |||
| 2.10 | 烤箱重量 | 净重(Net Weight) | 1000 | kgs | |
| 装箱(Gross Weight) | 1200 | kgs | |||
| 2.11 | 电源马达(Power ＆ motor) | 主机电源(Power Supply) | 380 | V | |
| 烤箱电源(Oven Supply) | 380 | V | |||
| 刮刀(Doctor Blade) | 0.75 | kw | |||
| 拉纸(Forward) | 1.5 | kw | |||
| 吸风马达(Air Suction Motor) | 0.37 | kw | |||
